Simplest way to migrate a SQL Server database to a lower version

The SQL Server database that has to move to SQL Server 2017 from a lower version.  After using it on SQL Server 2017, we had a request to get the database running on a SQL Server 2008 R2 instance to satisfy a need. We tried to do a backup and restore of the database, but we will get the error message:

Msg 1813, Level 16, State 2, Line 1
Could not open new database 'DatabaseName'. CREATE DATABASE is aborted.
Msg 948, Level 20, State 1, Line 1
The database 'DatabaseName' cannot be opened because it is version 655.
This server supports version 611 and earlier.
A downgrade path is not supported.

This error message is generated because SQL Server automatically upgrades the database when you restore or attach the database from a lower version to higher version and SQL Server does not allow you to restore or attach a database from a higher version of SQL Server to a lower version of SQL Server.

In this tip, we will look at a one time procedure which we can follow to downgrade the database from a higher version (SQL Server 2017) of SQL Server to a lower version (SQL Server 2008 R2) of SQL Server.

The error message in the problem statement occurs because the SQL Server database files (*.mdf, *.ndf and *.ldf) and backups are not backward compatible.  Backward compatibility is why we cannot restore or attach a database created from a higher version of SQL Server to a lower version of SQL Server. However, there are a few options that can help us to downgrade the database from a higher version of SQL Server to a lower version SQL Server. These options include:

1. Use the Generate Scripts Wizard in SQL Server Management Studio
2. Use SQL Server Integration Services
3. Create Custom Scripting and BCP(Bulk Copy Program()

In this article we will use the Generate Scripts Wizard in SQL Server Management Studio.
Here are the basic steps we need to follow:

• Script the database schema and data from the higher version of SQL Server by using the Generate Scripts Wizard in SSMS.
• Connect to the lower version of SQL Server, and run the SQL scripts that were generated in the previous step, to create the database schema and data.

Steps to Downgrade a SQL Server Database Using SSMS Generate Scripts Wizard

STEP 1:

Script the schema of the OUTLANDER database on the SQL Server 2017 instance (Admini\DEV01) using the Generate Scripts wizard in SSMS.

In Object Explorer connect to Admini\DEV01, right-click on the OUTLANDER database, expand Tasks and choose "Generate Scripts...".

 This launches Generate and Publish Scripts wizard. Click Next, to skip the Introduction screen and proceed to the Choose Objects page.

On the Choose Objects page, choose option "Script entire database and all database objects", and then click Next to proceed to "Set Scripting Options" page.

On the Set Scripting Options page, specify the location where you want to save the script file, and then click the Advanced button
In the Advanced Scripting Options dialog box,

• Set Script for Server Version to SQL Server 2008 R2 (or whatever version you want).
• Under the Table/View Options, set Script Triggers, Script Indexes and Script Primary Keys to True.
• Set Types of data to script to Schema and Data - this last option is key because this is what generates the data per table.

Once done, click OK, to close the Advanced Scripting Options dialog box and return to Set Scripting Options page. In Set Scripting Options page, click Next to continue to Summary page.

After reviewing your selections on Summary page, click Next to generate scripts.
Once scripts are generated successfully, choose the Finish button to close the Generate and Publish Scripts wizard.

STEP 2:

Connect to the SQL Server 2008 R2 instance (Admini\SQLSERVER2008), and then run the SQL scripts that were generated in Step 1, to create the OUTLANDER database schema and data.

In Object Explorer connect to Admini\SQLServer2008, then in SQL Server Management Studio, open the SQL Server script you saved in Step 1.

Modify the script, to specify the correct location for the OUTLANDER database data and log files. Once done, run the script to create the OUTLANDER database on Admini\SQLServer2008 instance.

Upon successful execution, refresh the Database folder in Object Explorer. As you can see in the following image, the OUTLANDER database has been successfully downgraded.

There are a few things to be aware of when using this approach.

1. This solution creates one large SQL file that has the scripts to create the database objects and also INSERT statements for the data in the tables.
2. For a large databases, the SQL file can get very large if you script out both the schema and the data and could be hard to load into an editor.  Also, you may get a memory related error message from the editor if the file is too big.
3. For large databases, around 1GB or more, if this approach does not work, then you should look at using SSIS to migrate the database or create custom scripts to script out the objects and BCP out the data for each of the tables.  You can use this Generate Scripts wizard to just generate the schema without the data and use SSIS or BCP to export and import the data.
4. This approach works for SQL Server 2017 to SQL Server 2005.  Some of the scripting options might be a bit different in newer versions, but the process is still the same.
5. Before just executing the script, you should review the script to make sure everything looks correct such as the path of the database files, database options, etc.
6. Also if you are using new functionality that does not exist in the lower version, SQL Server won't be able to create the objects and you will need to review the scripts that were generated and update the code accordingly.
7. For a very simple database this approach should work pretty easliy, but you might need to spend some time making some modifications to the script for a more complex database.
8. Below is a list of all of the scripting options. If you click on an item, the bottom part of the screen gives you a short definition of the option.

Additional Steps

• To avoid this issue, always make sure that you perform a full backup of the database before you upgrade the SQL Server and database to a higher version of SQL Server.  In addition, be sure to thoroughly test the application prior to releasing the application to the users.
• Consider this downgrade option as your last option to rollback from an upgrade because the time and storage needed can be very large.
• With a very large database be sure you have sufficient storage to support the data needs.
• Be sure to verify row and object counts as well as test your application before releasing to production.

Additional Resources:

• Migration using SQL Server Integration Services.
• Migration by creating Custom Scripts and Bulk Copy Program(BCP).
